drylin® E special stepper motor with terminal box, water protection, NEMA 23

  • Installation size: NEMA23/flange installation size 56 mm
  • Protection class motor housing: IP68 (10 m)
  • Holding torque: 1.30 Nm
  • Nominal current: 4.20 A
  • Motor connection: terminal box
Mô tả sản phẩm
The IP86 (underwater) stepper motors are ideally suited for applications in water and humid environments.

The IP68 motor can be used up to a depth of 10m (equivalent to 1 bar) and, together with the drylin® lead screw linear systems made of stainless steel or toothed belt axes UW, form a perfect underwater team.

Stepper motors from igus® are a good supplement to drylin® linear axes. They are characterised by their cost-effectiveness, their precision and easy control. They work reliably under the most varied environmental conditions (depending on the selected class of protection IP). The igus® stepper motors can be connected to the most common motor controls using standardised electrical connection.
Giấy chứng nhận và tiêu chuẩn
CE<br>EMV guideline
